From Keepalived to BGP Anycast: HAProxy HA on UniFi UDM Pro Max

UPDATE (March 3, 2026): Added BGP AS-Path Prepending section to resolve traffic flapping issues when both load balancers are active. This ensures a deterministic Active/Passive failover while maintaining BGP readiness.

I've been running two HAProxy boxes with Keepalived for years. Classic active/standby setup: one does the work, one sits there waiting for disaster. Works fine, but it always bugged me that half my capacity was just... idle.

Last week I finally dug into better options. Turns out you can do proper BGP anycast with a UniFi UDM Pro Max. No expensive Cisco gear needed. Here's how I got both HAProxy instances handling traffic simultaneously.

Where I Started

The original setup was dead simple:

Internet → VIP (Keepalived) → HAProxy01 (active)
                              → HAProxy02 (sitting idle)

Keepalived does its job well. HAProxy01 goes down, VIP floats to HAProxy02 in a couple seconds. But here's the thing: HAProxy02 has zero clue what sessions existed on HAProxy01. Users get kicked out, sticky sessions break. Not great.

First Fix: Sync Those Sessions

Before going crazy with BGP, there's a quick win. HAProxy can sync stick-tables between instances. When failover happens, the backup already knows about existing sessions.

Add this to both configs:

peers haproxy_cluster
    peer haproxy01 10.0.0.10:10000
    peer haproxy02 10.0.0.11:10000

Then hook it into your backends:

backend myapp_backend
    balance roundrobin
    stick-table type ip size 200k expire 30m peers haproxy_cluster
    stick on src
    server app01 10.0.0.10:8080 check
    server app02 10.0.0.11:8080 check

Now sessions survive failover. Users don't get logged out. This alone made a huge difference.

Keeping Configs in Sync

Two HAProxy boxes means two configs to maintain. I got tired of SSH'ing into both machines every time I changed something. HAProxy Data Plane API fixes this. Push changes via REST:

# Grab current config
curl -u admin:password "http://haproxy01:5555/v3/services/haproxy/configuration/raw"

# Push updated config
curl -u admin:password -X POST \
  "http://haproxy01:5555/v3/services/haproxy/configuration/raw?version=1" \
  -H "Content-Type: text/plain" \
  --data-binary @haproxy.cfg

I wrote a quick script that pushes to both nodes. Config drift problem solved.

The Real Upgrade: Both Boxes Working

Active/standby is fine, but why waste half your hardware? The goal was getting both HAProxy instances handling traffic at the same time.

Option 1: Two VIPs, DNS Round-Robin

VIP1 (10.0.0.100) → HAProxy01 (primary)
VIP2 (10.0.0.101) → HAProxy02 (primary)

DNS: lb.example.com → both IPs

Each HAProxy owns one VIP, backs up the other. DNS returns both, clients pick randomly. If one node dies, its VIP moves over. Works, but you're depending on DNS TTLs for failover.

Option 2: BGP Anycast on UDM Pro Max

This is what I actually went with. Both HAProxy boxes announce the same IP to the router. The router (my UDM Pro Max) sees two paths and load-balances between them.

I figured this needed fancy network gear. Nope. Turns out UniFi added BGP support in UniFi OS 4.1.13. If you've got a UDM Pro Max, UDM Pro, UDM-SE, or UXG-Enterprise, you can do this right now.

How It Looks

                    ┌─────────────────────┐
                    │    UDM Pro Max      │
                    │    AS 65000         │
                    │    10.0.0.1         │
                    └──────────┬──────────┘
                               │
                    BGP (eBGP) │ ECMP Load Balancing
                               │
            ┌──────────────────┼
            │                  │
     ┌──────▼──────┐    ┌──────▼──────┐
     │  HAProxy01  │    │  HAProxy02  │
     │  AS 65010   │    │  AS 65010   │
     │    .10      │    │    .11      │
     └──────┬──────┘    └──────┬──────┘
            │                  │
            └────────┬─────────┘
                     │
              Anycast VIP
            10.0.0.100

Both HAProxy nodes announce 10.0.0.100. The UDM sees two equal paths, splits traffic between them. One goes down, BGP withdraws the route, traffic flows to the survivor. No DNS delays.

Pro Tip: Fixing Traffic Flapping with AS-Path Prepend

While Anycast Active-Active sounds great, some stateful applications (Workflow engines, Streaming, Documentation portals) can suffer if the UDM Pro Max decides to switch paths mid-session. This is called traffic flapping.

The solution is to keep both BGP sessions up but make one HAProxy less attractive to the router. HaProxy01 becomes the primary, and HAProxy02 is the hot-standby.

On your backup HAProxy, update your /etc/frr/frr.conf:

router bgp 65010
  neighbor 10.0.0.1 route-map PREPEND out
!
route-map PREPEND permit 10
  set as-path prepend 65010 65010 65010

This makes the path via HaProxy02 look much "longer" to the UDM, forcing it to use HaProxy01 as long as it is available. If 01 fails, the route is withdrawn and 02 takes over in seconds with ZERO flapping.

Setting It Up

Step 1: FRRouting on the HAProxy Boxes

# On both HAProxy servers
apt update && apt install -y frr frr-pythontools

# Turn on BGP
sed -i 's/bgpd=no/bgpd=yes/' /etc/frr/daemons
systemctl restart frr

Step 2: FRR Config (HAProxy01)

# /etc/frr/frr.conf
frr version 8.5
frr defaults traditional
hostname haproxy01
!
router bgp 65010
 bgp router-id 10.0.0.10
 no bgp ebgp-requires-policy
 !
 neighbor 10.0.0.1 remote-as 65000
 neighbor 10.0.0.1 description UDM-Pro-Max
 !
 address-family ipv4 unicast
  network 10.0.0.100/32
  neighbor 10.0.0.1 activate
  neighbor 10.0.0.1 soft-reconfiguration inbound
 exit-address-family
!

HAProxy02 is identical, just change the router-id to .11.

Step 3: Add the VIP to Loopback

The anycast IP needs to exist on both boxes:

# /etc/network/interfaces.d/anycast
auto lo:0
iface lo:0 inet static
    address 10.0.0.100/32

# Bring it up
ifup lo:0

Step 4: UDM Pro Max BGP Config

Configure neighbors via UniFi Network → Settings → Routing → BGP:

router bgp 65000
 bgp router-id 10.0.0.1
 !
 neighbor 10.0.0.10 remote-as 65010
 neighbor 10.0.0.10 description HAProxy01
 !
 neighbor 10.0.0.11 remote-as 65010
 neighbor 10.0.0.11 description HAProxy02
 !
 address-family ipv4 unicast
  neighbor 10.0.0.10 activate
  neighbor 10.0.0.10 soft-reconfiguration inbound
  neighbor 10.0.0.11 activate
  neighbor 10.0.0.11 soft-reconfiguration inbound
  maximum-paths 2
 exit-address-family
!

Step 5: Open the Firewall

BGP runs on TCP 179. In UniFi Network, add a firewall rule:

Type: LAN In
Source: 10.0.0.10, 10.0.0.11
Destination: Gateway
Port: TCP 179
Action: Allow

Did It Work?

Check BGP status on the HAProxy boxes:

# Should show Established
sudo vtysh -c "show ip bgp summary"

# Check what you're advertising
sudo vtysh -c "show ip bgp neighbors 10.0.0.1 advertised-routes"

On the UDM Pro Max (SSH in):

# Should show two nexthops for the VIP
ip route show 10.0.0.100

# Expected output:
# 10.0.0.100 proto bgp
#   nexthop via 10.0.0.10 weight 1
#   nexthop via 10.0.0.11 weight 1

What I Run Now

HAProxy Peers for session sync
Data Plane API for config management
BGP anycast via UDM Pro Max

Both boxes handle traffic. One dies, the other picks up everything automatically. Sessions survive because of peer sync. It's proper active-active without any DNS hacks or slow failovers.

Quick Reference

Approach	Effort	When to Use
Keepalived only	Low	Simple setups, you don't mind idle hardware
Dual VIPs + DNS	Medium	Router doesn't support BGP
BGP Anycast	Medium	You want real active-active with fast failover

Handy Commands

# HAProxy peer status
echo "show peers" | socat stdio /run/haproxy/admin.sock

# BGP summary
sudo vtysh -c "show ip bgp summary"

# What routes am I advertising?
sudo vtysh -c "show ip bgp neighbors 10.0.0.1 advertised-routes"

# Reload HAProxy without dropping connections
systemctl reload haproxy

Bonus: AI-Powered HAProxy Management

Here's something I didn't expect to love this much. My load balancers expose their configuration via REST endpoints. Paired with a local AI assistant, management is now done in plain English / French:

"Drain the backend server for maintenance"
"Show me the stats for all backends"
"Add a new server to the cluster"
"Block external access to the admin panel"

The AI translates my request into the right API calls, executes them, and confirms the result. No more digging through config files or remembering complex syntax.

Me: "Put the blog server in maintenance mode"

AI: Done. Drained node 01 in backends.
    Active connections will finish, new requests
    go to other servers. Want me to re-enable it later?
